Generally speaking, this equipment is helpful for the following industries: food, Spices, chemical, pharmaceutical, and others. It is made especially to grind hard, solid materials like plastic, copper cables, trash, and so forth. It can also function as an additional piece of equipment for the process of fine grinding.
Using a fixed knife and a revolving knife, the LL Nutmeg Coarse Crusher for the horizontal crushing structure crushes and shears the material as it enters the crushing chamber. The material then automatically flows out of the opening.
The spindle of the horizontally oriented LL Nutmeg Coarse Crusher is supported by two rolling bearings. It is equipped with two movable frames, each of which contains a total of three moving blades.
| Model | CAPACITY (kg) | Feed size(mm) | Output size(mm) | Total power(kw) | Main speed(r/min) | Dimension(mm) | Weight (kg) |
| CSJ-80 | 20-50 | <50 | 0.5-20 | 1.5 |
~500 | 510*450*980 | 120 |
| CSJ-120 | 50-300 | <100 | 0.5-20 | 3 | 650*700*1200 | 250 | |
| CSJ-200 | 100-400 | <200 | 0.5-20 | 5.5 | 700*800*1200 | 420 | |
| CSJ-400 | 200-600 | <200 | 0.5-20 | 7.5 | 1200*1000*1360 | 800 | |
| CSJ-600 | 300-800 | <200 | 0.5-20 | 22 | 1300*1000*1400 | 1000 | |
| CSJ-1200 | 500-1500 | <200 | 0.5-20 | 37 | 1400*1000*1850 | 1300 |
